Commodity Model:TLS850B0TE

Trade Name:LDO Linear Regulator

Brand:INFINEON

Particular Year:25+

Package:TO-252-5

Delivery Date:New and Original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
INFINEON
Model
TLS850B0TE
Package
TO-252-5
Describe
OPTIREG™ Very Low Dropout Linear Regulator, TO-252-5

Product Description

TLS850B0TE: 5V, High Performance, OPTIREG™ Very Low Dropout Linear Regulator, TO-252-5


Model No.: TLS850B0TE

Package: TO-252-5

Type: Linear Regulator

Overview:

The TLS850B0TE is a high performance, very low dropout linear regulator in the PGTO252-5 package with a 5.0 V supply voltage.

The TLS850B0TE is intended for use in automotive systems that require operation in the cranking state. The device can be switched on and off with the enable function. Internal protection features such as output current limiting and overtemperature shutdown prevent immediate damage to the device due to faults such as output short to GND, overcurrent, and overtemperature.


TLS850B0TE - Product Attributes:

Series: OPTIREG™

Output Configuration: Positive

Output Type: Fixed

Number of Regulators: 1

Voltage - Input (Max): 40V

Voltage - Output (Min/Fixed): 3.3V

Voltage Drop (Max): 0.6V @ 250mA

Current - Output: 500mA

Current - Static (Iq): 25 µA

Current - Supply (Max): 33 µA

PSRR: 63 dB (100 Hz)

Control Features: Enable

Protection Features: Overcurrent, Over Temperature

Operating Temperature: -40°C ~ 150°C (TJ)

Mounting Type: Surface Mount

Package/Housing: TO-252-5, DPAK (4 Leads + Lugs), TO-252AD

Supplier Device Package: PG-TO252-5


TLS850B0TE - Product Features:

Wide input voltage range of 3.0 V to 40 V

Fixed output voltage 5.0 V

Output voltage accuracy ≤ ±2

Output current capability up to 500 mA

Ultra-low current consumption, 20 μA typical

Very low voltage drop, 100 mV @100 mA typical

Stable with 1 μF ceramic output capacitors

Over-temperature shutdown

Output current limiting

Wide temperature range
