The AD9779ABSVZ is a dual-channel, 16-bit, wide dynamic range digital-to-analogue converter (DAC) that provides a 1 GSPS sampling rate, allowing multicarrier generation up to Nyquist frequencies.

Product Features

Ultra-low noise and intermodulation distortion (IMD) for high-quality synthesis of broadband signals from baseband to high-midrange

Dynamic performance provided by proprietary digital analogue-to-digital converter output conversion technology

Current output configurations can be easily provided for a variety of single-ended or differential current topologies

CMOS data input interface with adjustable set and hold

Novel 2×, 4×, and 8× classifier/coarse-modulation synthesis regulators allow carrier placement in any bandwidth of the DAC

Product Attributes - AD9779ABSVZ

Product Category: Digital to Analogue Converters - DACs

Family: AD9779A

Resolution: 16 bit

Sample ratio: 1 GS/s

Number of Channels: 2 Channel

Output Type: Current

Interface type: Parallel

Analogue supply voltage: 1.8 V, 3.3 V

Digital supply voltage: 1.8 V, 3.3 V

Minimum operating temperature: - 40 C

Maximum operating temperature: + 85 C

Mounting Style: SMD/SMT

Package / Case: TQFP-100

DNL - Differential Nonlinearity: +/- 2.1 LSB

INL - Integral non-linearity: +/- 6 LSB

Number of Converters: 2 Converter

Pd-power dissipation: 300 mW

Applications

Wireless Infrastructure WCDMA, CDMA2000, TD-SCDMA, WiMax, GSM

Digital high IF or low IF synthesis

Internal digital upconversion capability

Transmit diversity

Broadband communication: LMDS/MMDS, point-to-point
