Service Telephone:86-755-83294757
Trade Name:DRA746PPIGABZQ1
Data Manual:DRA746PPIGABZQ1.pdf
Brand:TI
Particular Year:23+
Package:760-LFBGA
Delivery Date:New and Original
Stock: 1000pcs
The DRA746PPIGABZQ1 is programmable with a dual-core ArmCortex-A15 RISC CPU with Neon™ extensions, a TI C66x VLIW floating-point DSP core, and the Vision, AccelerationPac with one or more EVEs. With Arm, developers can reduce system software complexity by separating control functions from other algorithms programmed on the DSP and coprocessors.
In addition, TI offers a full suite of development tools for Arm, DSP and EVE coprocessors, including a C language compiler and a debugging interface to view source code.
Product Attributes
Core Processor: ARM® Cortex®-A15
Cores/Bus Width: 2 cores, 32-bit
Speed: 1.5GHz
Co-processor/DSP: ARM® Cortex®-M4, C66x, IVA
RAM Controller: DDR2, DDR3, DDR3l
Graphics Acceleration: Yes
Display and Interface Controller: HDMI, LCD
Ethernet: 10/100Mbps (1), 10/100/1000Mbps (1)
SATA: SATA
USB: USB 2.0 (3), USB 3.0 (1)
Voltage - I/O: 1.35V, 1.5V, 1.8V, 3.3V
Operating Temperature: -40°C ~ 125°C (TJ)
Safety features: boot safety, safe commissioning
Mounting Type: Surface Mount
Package/Housing: 760-LFBGA, FCBGA
Supplier Device Package: 760-FCBGA (23x23)
Additional interfaces: I²C, McASP, SPI, MMC/SD, UART
Applications
• Human Machine Interface (HMI)
• Navigation
• Digital and analogue radio
• Rear seat entertainment system
• Multimedia playback
• Web browsing capabilities
• ADAS Integration
• Integrated Automotive Digital Cockpit
• Infotainment/Centre Control Panel
