The ADG5401BRMZ is a single-chip industrial CMOS analog switch with a built-in anti-latch single-pole single-throw (SPST) switch. When switched on, the ADG5401BRMZ switch conducts electricity equally in both directions, and the input signal range can be extended to the supply voltage range. In the disconnected condition, the signal level at which the ADG5401BRMZ reaches the supply voltage is blocked.

The ADG5401BRMZ switch features ultra-low on-resistance and on-resistance flatness, making it an ideal solution for applications where low-distortion performance is critical for data acquisition and gain switching. The anti-latch construction and high ESD rating make these switches more stable in harsh environments.

Application scenario

The ADG5401BRMZ is suitable for a variety of application scenarios, including:

High-voltage signal routing

Automatic test equipment

Analog front-end circuit

Precision data acquisition system

Amplifier gain selection

Industrial instrument

Relay alternative

The ADG5401BRMZ switch has the following characteristics:

Anti-latch feature in all conditions

Human Body Model (HBM) ESD rating: 8 kV

Low on-resistance: 6.5Ω

±9 V to ±22 V dual power supply

9 V to 40 V single power supply

Maximum rated power supply voltage: 48 V

Rated supply voltage range: ±15 V, ±20 V, +12 V and +36 V

Analog signal range: VSS to VDD
