The LTC5589IUF is a direct conversion I/Q modulator designed for low power wireless applications that enables direct modulation of differential baseband I and Q signals on a single RF carrier. Single sideband modulation or sideband suppressed upconversion can be achieved by applying a 90° phase shift signal to the I and Q inputs. The I/Q baseband input port AC or DC can be coupled to a power supply with a common mode voltage level of approximately 1.4V.

Applications

Wireless microphone

Battery operated radio device

Vector modulator

Transmitters from 2.45GHz to 5.8GHz

Software Defined Radio (SDR)

Military radio

Technical specification

Frequency range: 700MHz to 6GHz

Low power: 2.7V to 3.6V power supply 29.5 mA

Low LO carrier leakage: -43dbm at 1.8GHz

Sideband suppression: -50 DBC at 1.8GHz

Output IP3:19dBm at 1.8GHz

Low RF output noise level: -157dBm/Hz (at 30MHz offset, PRF = 1.8dBm, fRF = 2.17GHz)

Sine wave or square wave LO drive

SPI control:

Adjustable gain: 19dB (1dB step)

Generated power supply current: 9mA to 39mA

I/Q offset adjustment: -64dbm LO carrier leak

I/Q gain/phase adjustment: -1DBC sideband suppression

24-pin 4mm x 4mm plastic QFN package
