Integrated Circuit Chip MAX22204ATU+ Stepper Motor Driver 38-WFQFN Half Bridge
Specifications
Operating Supply Voltage: 4.5 V to 65 V
Output Current: 3.8 A
Operating Supply Current: 5 mA
Minimum Operating Temperature: - 40 C
Maximum Operating Temperature: + 125 C
Product Description
MAX22204ATU+ is a two-phase stepper motor driver. It integrates two 65V, 3.8AMAX H-Bridges. The H-Bridge FETs have very low impedance, resulting in high driving efficiency and minimal heat.
Features
Two H-Bridges with +65V Voltage Rating
Total Rdson (High-Side + Low-Side): 300mΩ Typical (TA = 25°C)
Current Ratings per H-Bridge (Typical at TA = 25°C)
IMAX = 3.8AMAX (Impulsive Current for Driving Capacitive Loads)
IRMS = 2ARMS per Phase (TA = 25°C, VM = +24V)
Full-Scale DAC Current Configurable with External Resistance
One Logic Input (TRQ) to Quickly Change the Torque among Two Levels
