Model: EFR32BG21B010F768IM32-D (Bluetooth Low Energy SoC)

Package: QFN-32

Type: EFR32BG21 Series 2 Bluetooth Low Energy SoC

Overview:

The EFR32BG21B010F768IM32-D - EFR32BG21 Series 2 Wireless SoC contains an 80MHz ARM Cortex-M33 core for superior processing power. The device includes Secure Vault, 1024 kB Flash, 96 kB RAM, and is available in a QFN32 package. With a maximum output power of up to 20 dBm and excellent receive sensitivity of -97.1 (1 Mbit/s GFSK) dBm, the EFR32BG21B010F768IM32-D provides a robust RF link for reliable communication in Bluetooth 5.4 and Bluetooth mesh network applications.

EFR32BG21B010F768IM32-D Product Specifications:

Type: BLE Wireless SoC

Core: ARM Cortex M33

Operating Frequency: 2.4 GHz

Data Rate (Max): 2Mbps

Power - Output: 10dBm

Sensitivity: -105dBm

Storage Capacity: 768kB Flash, 64kB RAM

Serial Interfaces: GPIO, I2C, I2S, IrDA, PWM, SPI, UART, USART

GPIO: 20

Voltage - Supply: 1.71V ~ 3.8V

Current - Receive: 8.8mA ~ 9.8mA

Current - Transmit: 9.3mA ~ 186.5mA

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Package/Shell: 32-QFN (4x4)

• 1.Is the inventory and price seen on the platform accurate?

  A: all online goods on the shelves can be ordered online, but considering the large liquidity of spot inventory, it is not possible to achieve 100% accuracy at present. In case of any abnormality, you can contact our company online and give the corresponding solution.

• 2.Are all our products genuine?

  A: our self-supporting products are from cooperative domestic and foreign original factories or authorized agents, and the source can be traced to ensure the original and authentic products.

• 3.Can you provide the qualification certificate of the original factory or agent?

  A: at present, our self-employed brands TI，ST，ADI，NXP，LATTICE，CYPRESS，INFINEON，XILINX and other first-line brands. Other channels are the original factory and agency channels. If necessary, we can communicate and confirm according to the specific brand and model.

• 4.Can I make an inquiry through the company's website?

  A: You can inquire through the website, or by phone and email.

• 5.When can I deliver the goods after placing an order? How long will it take to get there?

  A: the delivery date is marked in most commodity information. You can estimate the delivery time of the commodity according to the delivery date. The specific arrival time depends on the warehouse where the commodity is located and the logistics mode you choose.

• 6.Can the company issue an invoice?

  A: you can issue ordinary invoices for individual users or special VAT invoices for enterprise users.
