The IWRL1432BDBAAMFR is an integrated single-chip millimeter wave sensor based on FMCW radar technology. The device is capable of operating in the 76GHz to 81GHz band and is divided into four main power domains:
Rf/Analog subsystem: This block contains all the RF and analog components needed to send and receive RF signals.
Front-end Controller Subsystem (FECSS) : FECSS contains the processor responsible for radar front-end configuration, control, and calibration.
Application Subsystem (APPSS) : In APPSS, the device implements a user-programmable ARM Cortex M4 that allows custom control and automotive interface applications. The Top Subsystem (TOPSS) is part of the APPSS power domain and contains clock and power management subblocks.
Hardware Accelerator (HWA) : The HWA block complements the APPSS by offloading common radar processing such as FFT, constant false alarm rate (CFAR), scaling, and compression.
The IWRL1432 is specifically designed to control each of these power domains individually, so its state (power-on or power-off) can be controlled according to the use case requirements.
FMCW Transceiver:
Integrated PLL, transmitter, receiver, baseband and ADC
Coverage range from 76GHz to 81GHz with continuous bandwidth of 5GHz
Three receiving channels and two transmitting channels
Short distance
Typical output power per Tx is 11dBm
14dB typical noise figure
Typical phase noise at 1MHz is -89dBc/Hz
FMCW running
5MHz IF bandwidth, real part Rx channel only
Ultra-precise linear frequency modulation pulse engine based on fractional NPLL
Each transmitter binary phase shifter
Model
Brand
Package
Quantity
Describe
TI
FCCSP-102
3000
Single-chip low-power 76GHz to 81GHz industrial millimeter wave radar sensors
TI
FCCSP-102
3000
Single-chip low-power 76GHz to 81GHz industrial millimeter wave radar sensors
TI
FCCSP-102
3000
Single-chip low-power 76GHz to 81GHz industrial millimeter wave radar sensors
TI
FCCSP-266
3000
Single-chip 76GHz to 81GHz industrial high-performance radar sensors
TI
FCCSP-266
3000
Single-chip 76GHz to 81GHz industrial high-performance radar sensors
TI
FCBGA-161
2000
60GHz to 64GHz single-chip smart millimetre wave sensor with integrated processing
TI
FCCSP-161
1000
60GHz to 64GHz single-chip smart millimetre wave sensor with integrated processing
