The MSC40SM120JCU2 is A 1200 V, 55 A silicon carbide power MOSFET module.

Specifications:

FET type: N channel

Technology: SiCFET (Silicon carbide)

Drain-source voltage (Vdss) : 1200 V

Current at 25°C - Continuous Drain (Id) : 55A (Tc)

Drive voltage (Max Rds On, min Rds On) : 20V

On-resistance (Max.) at different ids and Vgs: 50 milliohm @ 40A, 20V

Vgs(th) (Max.) : 2.7V@1mA for different ids

Gate charge (Qg) at different Vgs (Max.) : 137 N@20 V

Vgs (Max.) : +25V, -10V

Input capacitance (Ciss) at different Vds (Max.) : 1990 PF-@1000 V

FET function: -

Power dissipation (Max.) : 245W (Tc)

Operating temperature: -55°C ~ 150°C (TJ)

Installation type: Base installation

Supplier Device Package: SOT-227 (ISOTOP®)

Package/housing: SOT-227-4, miniBLOC

Applications:

AC and DC motor control

Switching mode power supply

Power factor correction

Brake switch
