ADMFM2000ABVZ is a dual-channel microwave downconverter, with input RF and local oscillator (LO) frequency ranges covering 5 GHz to 32 GHz, with an output intermediate frequency (IF) frequency range from 0.5 GHz to 8 GHz. The downconverting mixer can also be bypassed allowing direct access to the 0.5 to 8 GHz IF path. A common LO input signal is split to feed two separate buffer amplifiers to drive the mixer in each channel. Each down conversion path consists of a low noise amplifier (LNA), a mixer, an IF filter, a digital step attenuator (DSA), and an IF amplifier.

Features

Dual-channel, 0.5 GHz to 32 GHz receiver

Integrated LNA

Integrated downconversion mixer

Integrated switch for mixer bypass

Integrated IF LPF: 8 GHz bandwidth

Integrated DSA

DSA range: 31 dB with 1 dB step

Single common LO input

50 Ω matched input and output

20.00 mm × 14.00 mm, 179-ball CSP_BGA

Applications

Phased array radar receivers

Satellite communications (satcom) receivers v Electronic warfare

Electronic test and measurement equipment

Automatic test equipment
