The SYM-14H is a radio frequency mixer produced by Mini-Circuits, operating at frequencies ranging from 100MHz to 1.37GHz. It is suitable for radio frequency signal processing scenarios, such as signal modulation and demodulation in communication equipment or electronic test equipment.

Product features

• Wide bandwidth, 100 to 1370 MHz

Low conversion loss, with a typical value of 6.5 dB.

• High IP3, typical value 30 dBm

• Excellent matching of LO VSWR, typical value of 1.25:1; RF VSWR, typical value of 1.6:1

Good L-R isolation, with a typical value of 36 dB.

Target application

• Cellular

Ultra-high frequency television

• ISM

Technical specifications

Product: SYM-14H

Radio frequency: 100 MHz to 1.37 GHz

Conversion loss - maximum: 8.9 dB

LO frequency: 100 MHz to 1.37 GHz

Medium frequency: 10 MHz to 1 GHz

Maximum operating temperature: + 85 ° C

Minimum operating temperature: -40 ° C

Installation style: SMD/SMT

Packaging/Box: 9.65mm x 12.7mm x 5.84mm

Trademark: Mini-Circuits

OIP3 - Third-order cut-off point: 30 dBm

Product Type: RF Mixer
