Commodity Model:LMK1D1208IRHAR

Trade Name:Clock Buffer

Brand:TI

Particular Year:24+

Package:VQFN-40

Delivery Date:New and Original

Stock: 3000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
TI
Model
LMK1D1208IRHAR
Package
VQFN-40
Describe
8-Channel Output 1.8V, 2.5V and 3.3V LVDS Buffers with I²C

Product Description

The LMK1D1208IRHAR is an I 2C programmable LVDS clock buffer. The device features two inputs and eight pairs of differential LVDS clock outputs (OUT0 to OUT7) with ultra-small latency for clock distribution. The inputs can be LVDS, LVPECL, LVCMOS, HCSL, or CML.


The device is designed to drive 50Ω transmission lines. (Apply the appropriate bias voltage to the unused negative input pin when driving the input in single-ended mode).


Type: Clock Buffer

Number of Circuits: 1

Ratio - Input:Output: 2:8

Differential - Input:Output: Yes/Yes

Inputs: CML, HCSL, LVCMOS, LVDS, LVPECL

Output: LVDS

Frequency - Max: 2 GHz

Voltage - Supply: 1.71V ~ 1.89V, 2.375V ~ 2.625V, 3.135V ~ 3.465V

Operating Temperature: -40°C ~ 105°C (TA)

Mounting Type: Surface Mount

Package/Housing: 40-VFQFN Exposed Pad

Supplier Device Package: 40-VQFN (6x6)


Applications

- Telecom & Networking

- Medical Imaging

- Test and Measurement Equipment

- Wireless Communications

- Professional Audio/Video
