Trade Name:Analogue Switch
Brand:ST
Particular Year:24+
Package:QFN16
Delivery Date:New and Original
Stock: 1000pcs
The STG5592QTR is a high-speed CMOS low-voltage quad analogue SPDT (single-pole, double-throw) switch or 2:1 multiplexer/demultiplexer switch developed using silicon gate CMOS technology. It operates from 1.65 V to 5.5 V, making it ideal for portable applications.
All Features
Wide operating voltage range:
Single supply VCC (opr) = 1.65 V to 5.5 V
Low on-resistance:
Ron (peak) = 2.75 Ω at VCC = 5 V ( TA = 25 °C)
Compatible with 1.8 V logic
Fail-safe logic
Low power consumption:
ICC= 0.1 µA at TA= 25 °C
ICC= 25 µA at TA= 125 °C
Typical bandwidth at 500 MHz for all channels (-3 dB)
-40 °C to +125 °C operating temperature
USB (2.0) high speed (480 Mbps) signal switching compliant
