AD8233ACBZ - 50µA, Low Noise, Heart Rate Monitor for Wearable Products

Part Number: AD8233ACBZ

Package: WLCSP-20

Type: ECG Front End

Description: Analog Front End - ECG Front End 20-WLCSP (2x1.7)

Product Overviews

AD8233ACBZ is an integrated signal conditioning block for electrocardiogram (ECG) and other biopotential measurement applications. The AD8233 implements a two-pole, high-pass filter for eliminating motion artifacts and the electrode half cell potential. This filter is tightly coupled with the instrumentation amplifier architecture to allow both large gain and high-pass filtering in a single stage, thereby saving space and cost.

Product Features

Fully integrated, single-lead ECG front end

Low quiescent supply current: 50µA (typical)

Leads on/off detection while in shutdown (<1µA)

Common-mode rejection ratio: 80dB (dc to 60Hz)

2-electrode and 3-electrode configurations

High signal gain (G = 100) with dc blocking capabilities

2-pole adjustable high-pass filter

Accepts up to ±300mV of half cell potential

Fast restore feature improves filter settling

3-pole adjustable low-pass filter with adjustable gain

Integrated RLD amplifier with shutdown

Single-supply operation: 1.7V to 3.5V

Rail-to-rail output

8 kV HBM ESD rating

Applications

Fitness and activity heart rate monitors

Portable ECG

Wearable and remote health monitors

Biopotential signal acquisition, such as EMG or EEG
