Trade Name:ADUM4223WCRWZ
Brand:ADI
Particular Year:23+
Package:16-SOIC
Delivery Date:New and Original
Stock: 2000pcs
ADUM4223WCRWZ - 4A Output Isolated Precision Half-Bridge Driver
Product Description
ADUM4223WCRWZ is 4 A isolated, half-bridge gate drivers. It provides 5000 V rms isolation in the wide body, 16-lead SOIC package. Combining high speed CMOS and monolithic transformer technology, these isolation components provide outstanding performance characteristics superior to the alternatives, such as the combination of pulse transformers and gate drivers.
Product Features
4 A peak output current
Working voltage
High-side or low-side relative to input: 537 V peak
High-side to low-side differential: 800 V peak
High frequency operation: 1 MHz maximum
3.3 V to 5 V CMOS input logic
4.5 V to 18 V output drive
CMOS input logic levels
High common-mode transient immunity: >25 kV/µs
Enhanced system-level ESD performance per IEC 61000-4-x
High junction temperature operation: 125°C
Thermal shutdown protection
Default low output
Applications
Switching power supplies
Isolated IGBT/MOSFET gate drives
Industrial inverters
