Trade Name:STGAP1BS
Brand:ST
Particular Year:23+
Package:24-SOIC
Delivery Date:New and Original
Stock: 1000pcs
The STGAP1BS is a galvanically isolated single gate driver for N-channel MOSFETs and IGBTs with advanced protection, configuration, and diagnostic features.The STGAP1BS architecture isolates the channel from the control and low-voltage interface circuits through true galvanic isolation. The gate driver has a 5 A capability, making it also suitable for high power inverter applications such as motor drives in hybrid and electric vehicles and industrial drives. The output driver section provides rail-to-rail outputs, allowing the use of negative gate driver power supplies.
Functionality
● AEC-Q100 certified
● High voltage rail up to 1500 V
● Drive current capability: 5 A sink/source at 25 °C
● dV/dt transient immunity: ±50 V/ns over full temperature range
● Overall input/output propagation delay: 100 ns
● Separate sink and source currents for easy gate drive configuration
● Negative gate drive capability
● Active Miller clamp
● Desaturation detection
● SENSE input
● VCE active clamp
APPLICATIONS
● 600/1200 V inverters
● EV/HEV inverters
● Electric vehicle charging stations
● Industrial drives
● UPS devices
● DC/DC converters
● Solar inverters
