The ICE3BR4765JG is an integrated avalanche capable 650V CoolMOS™, starter unit and starter unit, and fixed frequency current mode flyback PWM controller in a DSO-12 package. Suitable for 14W SMPS design. Additional features include active burst mode operation for extremely low standby power consumption, frequency jitter for low EMI, adjustable blanking Windows that promote load jumping, and a high-voltage start unit that allows the controller to be quickly booted from the rectifier line.

specification

Output quarantine: Quarantine

Internal switch: Yes

Voltage - breakdown: 650V

Topology: flyback

Voltage - Starting: 18 V

Voltage - power supply (Vcc/Vdd) : 10.5V ~ 27V

Duty cycle: 75%

Frequency - Switch: 65kHz

Power (W) : 24 W

Fault protection: current limiting, overload, overtemperature, overvoltage

Control characteristics: -

Operating temperature: -40°C ~ 150°C (TJ)

Package/housing: 16-SOIC (0.154", 3.90mm wide), 12 leads

Supplier device package: PG-DSO-12-10

Mounting type: Surface mount type

Basic product number: ICE3BR4765
