ADUC7023BCP6Z62IR7 - Precision Analog Microcontroller, 12-Bit Analog I/O, ARM7TDMI MCU with Enhanced IRQ Handler

Product Description

ADUC7023BCP6Z62IR7 is a fully integrated, 1 MSPS, 12-bit data acquisition system, incorporating high performance multichannel ADCs, 16-bit/32-bit MCUs, and Flash/EE memory on a single chip. The ADC consists of up to 12 single-ended inputs. An additional four inputs are available but are multiplexed with the four DAC output pins.

Product Attributes

Core Processor ARM7®

Core Size 16/32-Bit

Speed 44MHz

Connectivity I²C, SPI

Peripherals POR, PWM, WDT

Number of I/O 20

Program Memory Size 62KB (31K x16)

Program Memory Type FLASH

RAM Size 2K x 32

Voltage - Supply (Vcc/Vdd) 2.7V ~ 3.6V

Data Converters A/D 12x12b; D/A 4x12b

Oscillator Type Internal

Operating Temperature -40°C ~ 125°C (TA)

Mounting Type Surface Mount

Package / Case 40-WFQFN Exposed Pad, CSP

Supplier Device Package 40-LFCSP-WQ (6x6)

Applications

Optical networking

Industrial control and automation systems

Smart sensors, precision instrumentation

Base station systems
