Service Telephone:86-755-83294757
Trade Name:BTS5090-1EJA
Data Manual:BTS5090-1EJA.pdf
Brand:INFINEON
Particular Year:14+
Package:SOP8
Delivery Date:New and Original
Stock: 5000pcs
The BTS5090-1EJA is a 90 mΩ single-channel intelligent high-side power switch in a PG-DSO-8-43 EP exposed pad package that provides protection features and diagnostics. The power transistor is built from an N-channel vertical power MOSFET with charge pump. The device integrates Smart6 technology. It is specifically designed to drive lamps up to 1 * P21W and LEDs in harsh automotive environments.
Product Attributes
Product Category: Power Switch ICs - Power Distribution
Type: High Side
Number of Outputs: 1 Output
Output Current: 3 A
Current Limit: 20 A
On-resistance - max: 90 mOhms
Runtime - max: 230 us
Idle time - max: 230 us
Operating supply voltage: 5 V to 28 V
Minimum operating temperature: - 40 C
Maximum operating temperature: + 150 C
Mounting style: SMD/SMT
Package / Case: SOIC-8
Series: PROFET 12V
Qualification: AEC-Q100
Humidity Sensitivity: Yes
Pd-Power Dissipation: 1.5 W
Factory Package Quantity: 2500
Supply Voltage - Max: 28 V
Supply Voltage - Min: 5 V
Applications
For resistive, inductive, and capacitive loads
Replaces electromechanical relays, fuses and discrete circuits
Ideal for high inrush current loads such as luminaires
