LMP92066PWPR is a highly integrated temperature controlled dual DAC. Both DACs can be programmed by two independent, user-defined, temperature-to-voltage transfer functions stored in the internal EEPROM,allowing any temperature effects to be corrected without additional external circuitry.

Features

Intermal 12-Bit Temperature Sensor

Accuracy(- 40°C to 120°C), +3.2°C

Two Independent Transfer Functions Stored in EEPROM

Dual-Analog Output

Two 12-Bit DACs

Output Range 0 V to 5V or0V to-5 V

High-Capacitive Load Tolerant, up to 10 μF

Post-Calibration Accuracy +2.4 mV (typical)

Output On/Off Control Switching Time 50 ns

Switching Time 50 ns (typical)

RDSON 5 Q (maximum)

IC Interface: Standard and Fast

Nine Selectable Slave Addresses

TIMEOUT Function

VDD Supply Range 4.75 V to 5.25 V

Specified Temperature Range - -25°C to 120C

Operating Temperature Range - -40°C to 125°C

Applications

GaN or LDMOS PA Bias Controller

Sensor Temperature Compensation

Timing Circuit Temperature Compensation
