The LMR36506RS3QRPERQ1 is the industry's smallest 65 V, 0.6 A synchronous step-down DC/DC converter in the industry's smallest 65 V, 0.6 A synchronous step-down DC/DC converter in a 2-mm x 2 mm HotRod™ package. This easy-to-use converter handles transient input voltages up to 70 V, provides excellent EMI performance, and supports fixed 3.3 V, 5 V, and other adjustable output voltages.The LMR36506RS3QRPERQ1 features a peak-current-mode control architecture with internal compensation and maintains a stable output voltage. Stable operation is maintained with minimal output capacitance.The LMR36506RS3QRPERQ1's wide input operating range helps in severe input voltage making it an excellent choice for automotive applications.The PGOOD logo in the LMR36506RS3QRPERQ1 accurately displays the status of the output voltage without the need for an external monitor. The seamless transition from FPWM to PFM and ultra-low standby quiescent current enable the LMR36506-Q1 to support higher system efficiency at low output loads.

Product Attributes

Function: Buck

Output Configuration: Positive

Topology: Buck

Output Type: Fixed

Number of Outputs: 1

Voltage - Input (Min): 3V

Voltage - Input (Max): 65V

Voltage - Output (Min/Fixed): 3.3V

Voltage - Output (Maximum): - Voltage - Output (Maximum): - Voltage - Output (Maximum): - Voltage

Current - Output: 600mA

Frequency - Switch: 200kHz ~ 2.2MHz

Synchronous Rectifier: Yes

Operating Temperature: -40°C ~ 125°C (TA)

Mounting Type: Surface Mount, Wettable Sides

Package/Housing: 9-VFQFN

Supplier Device Package: 9-VQFN-HR (2x2)

Applications

● Advanced Driver Assistance Systems (ADAS)

● Body electronics and lighting

● Infotainment and clustering
