The TPS22975DSGT is a single-channel load switch offering configurable rise times to minimise inrush current. This device incorporates an N-channel metal-oxide-semiconductor field-effect transistor (MOSFET) operating within an input voltage range of 0.6 V to 5.7 V and supporting a maximum continuous current of 6 A. The switch is controlled by an ON/OFF input (ON), which can be directly connected to a low-voltage control signal. The TPS22975DSGT incorporates an optional 230Ω on-chip load resistor for rapid output discharge when the switch is turned off.

The TPS22975DSGT is housed in a compact, space-saving 2mm × 2mm 8-pin SON package (DSG). An integrated thermal pad enables the device to dissipate high power. It is rated for operation over a natural convection ambient temperature range of –40°C to +105°C.

TPS22975DSGT Features

• Integrated single-channel load switch

• Input voltage range: 0.6V to VBIAS

• VBIAS voltage range: 2.5V to 5.7V

• On-resistance (RON)

– RON = 16mΩ (typical at VIN = 0.6V to 5.7V, VBIAS = 5.7V)

• 6A maximum continuous switching current

• Low quiescent current

– 37µA (typical at VIN = VBIAS = 5V)

• Low control input threshold supporting 1.2V, 1.8V, 2.5V, 3.3V logic devices

• Configurable rise time

• Thermal shutdown

• Quick Output Discharge (QOD) (optional)

• Small Outline No-Lead (SON) 8-pin package with thermal pad

• Tested to meet JESD 22 specifications for electrostatic discharge (ESD) performance

– 2000V Human Body Model (HBM) and 1000V Conducted Device Model (CDM)

TPS22975DSGT Product Attributes

Manufacturer: Texas Instruments

Product Category: Power Switch IC - Power Distribution

Type: Load Switch

Number of Outputs: 1 Output

Output Current: 6 A

On-Resistance—Maximum: 16 mOhms

Turn-On Time—Maximum: 1.45 ps

Maximum Idle Time:    2 us

Operating Supply Voltage:    600 mV to 5.7 V

Minimum Operating Temperature:    -40°C

Maximum Operating Temperature:    +105°C

Mounting Style:    SMD/SMT

Package / Case:    WSON-8

Series:    TPS22975

TPS22975DSGT Applications

• Ultrabook™

• Laptops and netbooks

• Tablets

• Consumer electronics

• Set-top boxes and home gateways

• Telecommunications systems

• Solid-state drives (SSD)
