The MP5073GG load switch can provide 2A current load protection within an input operating voltage range of 0.5V to 5.5V. With its low on-resistance (RDSON) and extremely small package, it can provide an efficient and space-saving solution for laptops, tablets and other portable/battery-powered applications.

The MP5073GG offers a soft-start function, which can prevent the surge current generated during circuit startup. It simultaneously offers multiple protection functions such as adjustable soft start time, output discharge, overcurrent protection (OCP), and over-temperature shutdown protection.

Its features and advantages are as follows:

Integrated 50mΩ low on-resistance FET

Adjustable start slope

Wide operating input voltage range: 0.5V to 5.5V

The turn-off current is less than 1µA

Typical 2A current limiting range

Indication of normal power output

Output discharge function

Enable pin

The short-circuit protection response time is less than 200ns

Over-temperature protection

Space-saving small-sized QFN-12 (2mmx2mm) package

Application scenarios

The MP5073GG is suitable for battery-powered devices (such as power banks and Bluetooth devices), providing an efficient load protection solution.
