The ADW71205WSTZ is a complete 12-bit resolution tracking divider digital-to-analogue converter featuring an integrated programmable sine wave oscillator that provides sine wave excitation for the divider.

The converter's Sin and Cos inputs support input signals of 3.15 V p-p ± 27%. A Type II tracking loop is employed to track the input signal, converting information from the Sin and Cos inputs into corresponding digital values for input angle and rate. The maximum tracking rate is a function of the external clock frequency. The ADW71205WSTZ operates within a frequency range of 8.192 MHz ± 25%, achieving a maximum tracking rate of 1250 rps.

ADW71205WSTZ Features

Complete single-chip resolver-to-digital converter (RDC)

Parallel and serial 12-bit data ports

System fault detection

Accuracy: ±11 arc minutes

Input signal range: 3.15 V p-p ± 27%

Absolute position and rate outputs

Maximum tracking rate: 1250 rps

Resolution: 12 bits

Incremental encoder emulation

(1024 pulses/revolution)

Integrated programmable sine wave oscillator

Single supply voltage: 5.00 V ±5%

Rated temperature range: −40°C to +125°C

44-pin LQFP package

ADW71205WSTZ Applications

- Automotive motion sensing and control

- Hybrid electric vehicles

- Electric power steering

- Integrated starter-generator/alternator

- Industrial motor control

- Process control
