Commodity Model:TLV320AIC3104IRHBR

Trade Name:Audio Codec

Brand:TI

Particular Year:22+

Package:VQFN-32

Delivery Date:New and Original

Stock: 15000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
TI
Model
TLV320AIC3104IRHBR
Package
VQFN-32
Describe
Low power stereo codec with 6 inputs, 6 outputs, headphone amplifier and enhanced digital effects

Product Description

The TLV320AIC3104IRHBR is a low-power stereo audio codec with a stereo headphone amplifier and multiple inputs and outputs programmable in single-ended or fully differential configurations. The device includes comprehensive register-based power control, enables stereo 48kHz DAC playback and consumes as low as 14mW at 3.3 V analog supply voltage, making it ideal for portable battery-powered audio and telephony applications.


The recording path of the TLV320AIC3104IRHBR includes integrated microphone bias, CNC stereo microphone preamplifier and automatic gain control (AGC), and provides mixer/multiplexer functionality in multiple analog inputs. During recording, the programmable filter is capable of filtering out audible noise that may be generated during optical zooming of the digital camera. The playback path includes mixer/multiplexer function (from the stereo DAC and selected inputs, through programmable volume control to various outputs).


Characteristics of TLV320AIC3104IRHBR

Stereo Audio DAC:

102dBA SNR

16-, 20-, 24-, and 32-bit data

Supports sampling rates from 8kHz to 96kHz

3D, bass, treble, EQ, or de-accent effects

Provides flexible energy-saving modes and performance

Stereo Audio ADC:

92dBA SNR

Supports sampling rates from 8kHz to 96kHz

Provides digital signal processing and noise filtering during recording

Six audio input pins:

A pair of stereo single-ended inputs

A pair of stereo fully differential inputs

Six audio output drivers:

Stereo Full Differential or Single Ended Headphone Driver

Fully differential stereo line output

Low power consumption: 3.3 V analog supply voltage, 14mW stereo, 48kHz playback

Ultra-low power mode with passive analog bypass

Programmable I/O analog gain

Automatic gain control (AGC) for audio recording

Programmable microphone bias level

Programmable PLL for Flexible Clock Generation

I2C control bus

The audio serial data bus supports I2S, left and right balanced, DSP and TDM modes

Extensive modular power control

Power Supply:

Analog: 2.7 V to 3.6 V

Digital Core: 1.525 V to 1.95 V

Digital I/O: 1.1 V to 3.6 V

Package: 5 mm × 5 mm, 32-pin VQFN


Application of TLV320AIC3104IRHBR

• Headphones

• IP webcam

• IP Phone

• Wireless speakers

Associated Products

Model

Brand

Package

Quantity

Describe

ADAU1772BCPZ

ADI

LFCSP-40

3000

4 ADC, 2 DAC Low power codec with audio processor

DA7218-00U32

Renesas

32-WLCSP

2000

Ultra-Low Power Stereo Codec with Single-Ended Headphone Driver
