The ZSSC4165DE4R is an automotive grade sensor signal conditioner (Renesas) designed in CMOS process for high-precision measurement of differential bridge sensor signals. The ZSSC4165DE4R supports dual-differential full-bridge sensor elements (such as resistance Bridges, thermocouples, etc.), integrates internal chip temperature measurement and external RTD temperature measurement functions, and achieves digital compensation through a 16-bit RISC microcontroller, which can eliminate sensor signal offset, sensitivity, temperature drift and nonlinear errors.

Key features

Dual-channel for reading out resistance bridge sensors

A variety of internal and external temperature measurement options for compensation

The SENT output based on the SAE-J2716 specification 2010 and 2016 standards uses fast and serial data messages

Single-wire interface for end-of-line calibration

Powerful power management and EMC

AECQ-100 Level 0 certification

Application scenarios

The ZSSC4165DE4R is suitable for the automotive electronics field and features overvoltage/reverse voltage protection, electromagnetic compatibility optimization, and multi-diagnostic functions. It can output measurement data via the SENT or I²C interface.
