For picture reference, please see the specifications
< >

Commodity Model:TLE7257SJ

Trade Name:LIN Transceiver

Brand:INFINEON

Particular Year:22+

Package:PG-DSO-8

Delivery Date:New and Original

Stock: 5000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
INFINEON
Model
TLE7257SJ
Package
PG-DSO-8
Describe
Transceiver for Local Interconnect Networks (LIN) with integrated wake-up and protection functions

Product Description

The TLE7257SJ is a transceiver for the Local Interconnect Network (LIN) with integrated wake-up and protection features. It is designed for invehicle networks using data transmission rates up to 20 kbps. The TLE7257SJ  operate as a bus driver between the protocol controller and the physical bus of the LIN network. Compliant to all LIN standards and with a wide operational supply range the TLE7257SJ can be used in all automotive applications.


The usage of different operation modes and the INH output allows the TLE7257SJ to control external components like e.g. voltage regulators. In Sleep mode the TLE7257SJ draws typically less than 10 μA of quiescent current while still being able to wake-up when detecting LIN bus traffic. The very low leakage current on the BUS pin makes the TLE7257SJ especially suitable for partially supplied networks.


Based on the Infineon BiCMOS technology the TLE7257SJ provides excellent ESD robustness together with a very high electromagnetic compatibility (EMC). The TLE7257SJ reaches a very low level of electromagnetic emission (EME) within a broad frequency range and independent from the battery voltage. The TLE7257SJ is AEC qualified and tailored to withstand the harsh conditions of the automotive environment.


Features

• Single-wire LIN transceiver for transmission rates up to 20 kbps

• Compliant to ISO 17987-4, LIN Specification 2.2A and SAE J2602

• Very low current consumption in Sleep mode with wake-up capability

• Very low leakage current on the BUS pin

• Digital I/O levels compatible with 3.3 V and 5 V microcontrollers

• TxD protected with dominant time-out function and state check after mode change to Normal Operation mode

• BUS short to VBAT protection and BUS short to GND handling

• Over temperature protection and supply undervoltage detection

• Very high ESD robustness, ± 10 kV according to IEC61000-4-2

• Optimized for high electromagnetic compatibility (EMC); Very low emission and high immunity to interference

• Available in standard PG-DSO-8 packages

• Green Product (RoHS compliant)

• AEC Qualified


Applications

• Automotive secondary power distribution unit

• Domain controller for ADAS and autonomous driving

• EV traction inverter

Associated Products

Model

Brand

Package

Quantity

Describe

NCV7424DB0R2G

ON

TSSOP-16

10000

Quad-channel LIN transceiver

MLX80020KDC-BAA-000-RE

Melexis

SOIC-8

2500

Enhanced LIN Transceiver -LIN2.x spec compliant

MLX80002KLW-CAA-101-RE

Melexis

QFN-24

2000

Dual channel LIN master transceiver compliant with LIN 2.x/SAE J2602 standard

TLE7259-3LE

INFINEON

PG-TSON-8

2000

Transceiver 1/1 LINbus PG-TSON-8-1

TLE7258LE

INFINEON

PG-TSON-8

2000

Transceiver 1/1 LINbus PG-TSON-8-1

TLE7257LE

INFINEON

PG-TSON-8

2000

Transceiver 1/1 LINbus PG-TSON-8-1

TLE7268LC

INFINEON

PG-TSON-14

2000

Half transceiver 2/2 LIN PG-TSON-14-3

NCV7428MWL3R2G

ON

8-VDFN

2000

System Basis Chip with Integrated LIN and Voltage Regulator

NCV7428MW5R2G

ON

8-VDFN

2000

System Basis Chip with Integrated LIN and Voltage Regulator

ATA663255-GBQW

Microchip

8-VDFN

2000

1/1 Transceiver Half LIN 8-VDFN (3x3)
