MSPM0G1507SDGS28R: Mixed Signal Microcontroller - 32-bit ARM® Cortex®-M0+ Microcontroller IC, VSSOP-28

Model: MSPM0G1507SDGS28R

Package: VSSOP-28

Type: 32-bit Microcontroller - MCU

MSPM0G1507SDGS28R Specifications:

Core Processor: ARM® Cortex®-M0+

Core Specification: 32-bit

Speed: 80MHz

Connectivity DALI, I2C, IrDA, LINbus, Smartcard, SMBus, SPI, UART/USART

Peripherals AES, Power Down Detect/Reset, DMA, POR , PWM, TRNG, WDT

Number of I/O: 24

Program Memory Capacity: 128KB (128K x 8)

Program Memory Type: Flash

RAM Size: 32K x 8

Voltage - Supply (Vcc/Vdd): 1.62V ~ 3.6V

Data Converters: A/D 11x12b SAR;D/A 1x12b

Oscillator Type: External, Internal

Operating Temperature: - 40°C ~ 125°C (Vcc/Vdd) 40°C ~ 125°C (TA)

Mounting Type: Surface Mount

Vendor Device Package: 28-VSSOP

Package/Case: 28-TFSOP (0.118", 3.00mm wide)

MSPM0G1507SDGS28R Product Features:

Core

Arm 32-bit Cortex-M0+ CPU with Memory Protection Unit up to 80MHz

Operating Characteristics

Operating Temperature Range: -40°C to 125°C

Wide Supply Voltage Range: 1.62V to 3.6V

Memory

Error Correcting Code (ECC) and up to 128KB Flash Memory with Hardware Flash memory up to 128KB

SRAM with hardware parity up to 32KB

Enhanced communication interfaces

Four UART interfaces; one supports LIN, IrDA, DALI, Smart Card, Manchester, and three support low-power operation in STANDBY mode

Two I2C interfaces with FM+ (1Mbit/s) support, SMBus/PMBus and wake-up from STOP mode

Two SPIs, one SPI supporting up to 32Mbit/s
