TOP266KG is a high-performance offline switching power supply controller chip belonging to the TOPSwitch®-JX series. This chip integrates a 725V power MOSFET and PWM controller, supporting up to 58W output power. It is suitable for various power supply topologies, such as flyback switching power supplies.

TOP266KG Specifications

Maximum Output Power: 58W (open-frame design, 230V input)

Switching Frequency: Up to 132kHz

Input Voltage Range: 85V to 265V

Breakdown Voltage: 725V

Operating Temperature Range: -40°C to +150°C

Package Type: ESOP-12

Mounting Type: Surface Mount

Protection Features: Overcurrent protection, overload protection, overtemperature protection, overvoltage protection, short-circuit protection

Control Characteristics: Frequency dithering, soft start, auto-restart/latch fault response, on/off control

TOP266KG Features

High Efficiency & Energy Savings: High energy efficiency across the entire load range, with no-load power consumption below 70mW (230VAC input).

High Design Flexibility: Supports multi-mode PWM control to optimise efficiency under varying loads; 132kHz operating frequency reduces transformer and power supply size.

Comprehensive Protection: Features automatic restart, overcurrent protection, overload protection, overvoltage protection, and short-circuit protection to ensure system stability and safety.

Optimised EMI Performance: Frequency jitter technology reduces EMI filtering component costs.

Integrated soft-start: Reduces stress during power-up.

TOP266KG Application Scenarios

Consumer electronics: Smartphone chargers, tablet adapters, small appliance power modules.

Industrial equipment: Industrial automation power supplies, compact UPS systems, sensor network power sources.

Medical devices: Portable medical equipment power supplies.

LED lighting: LED lighting drivers.

Test and measurement equipment: Test instrument power supplies.
