OPA2991SIRUGR is a dual-channel, 40V, 4.5MHz bandwidth low-power operational amplifier suitable for high-precision signal conditioning, industrial control, and automotive electronics applications. This device is packaged in a 10-X2QFN (2×1.5mm) package, supports rail-to-rail input/output (RRIO), and features excellent DC accuracy and low noise characteristics, making it an ideal choice for sensor interfaces, data acquisition systems, and motor control circuits.

OPA2991SIRUGR Features

• Low offset voltage: ±125µV

• Low offset voltage drift: ±0.3µV/°C

• Low noise: 10.8nV/√Hz at 1 kHz

• High common-mode rejection: 130dB

• Low bias current: ±10 pA

• Rail-to-rail input and output

• Wide bandwidth: 4.5 MHz GBW

• High slew rate: 21 V/µs

• High capacitive load drive: 1 nF

• Supports multiplexer/comparator inputs

– The amplifier operates with differential inputs up to the power supply rail

– The amplifier can be used in open-loop mode or as a comparator

• Low quiescent current: 560 µA per amplifier

• Wide supply voltage range: ±1.35 V to ±20 V, 2.7 V to 40 V

• Robust EMIRR performance: EMI/RFI filters on input and power pins

• Differential and common-mode input voltage range relative to the power rail

OPA2991SIRUGR Parameters

Number of channels: 2

Supply voltage range: 2.7V to 40V (single supply)

Input offset voltage: ±125µV (typical), 0.75mV (maximum)

Gain-bandwidth product (GBW): 4.5MHz

Slew rate: 21V/µs

Output current: ±75mA

Package: 10-X2QFN (2×1.5mm)

OPA2991SIRUGR Applications

• Low-power audio preamplifiers

• Multiplexed data acquisition systems

• Test and measurement equipment

• ADC driver amplifiers

• SAR ADC reference buffers

• Programmable logic controllers

• High-side and low-side current sensing
