The IPA60R199CP is an N-channel power MOSFET from Infineon, part of the CoolMOS™ CP series, packaged in a TO-220FP (PG-TO-220-FP) package, suitable for high-efficiency power conversion, industrial power systems, and automotive electronics applications. This device employs advanced Super Junction technology, offering low on-resistance (RDS(on)), high switching speed, and excellent thermal performance, significantly enhancing system efficiency while reducing PCB space requirements.

Key Features

High voltage rating: 650V drain-source voltage (VDS), suitable for high-voltage applications such as AC-DC power supplies and solar inverters.

Low on-resistance: 199mΩ (maximum) @10V VGS, reducing conduction losses and improving energy efficiency.

High current capability: 16A continuous drain current (ID) (at 25°C, with case temperature limitation).

Fast switching performance: 5ns rise time, 5ns fall time, optimised for high-frequency switching applications.

Low gate charge (Qg): 32nC @10V, reducing drive losses and compatible with low-power control circuits.

Automotive-grade reliability: operating temperature -55°C to +150°C, compliant with RoHS lead-free standards, suitable for harsh environments.

Technical specifications

Model: IPA60R199CP

Package: TO-220FP (PG-TO-220-FP)

Drain-source voltage (VDS): 650V

Continuous drain current (ID): 16A

Pulse drain current (IDM): 51A

On-resistance (RDS(on)): 199mΩ (maximum) VGS=10V, ID=9.9A

Gate charge (Qg): 32nC VGS=10V

Input capacitance (Ciss):    1520pF    VDS=100V

Maximum power dissipation (PD): 34W    Tc=25°C

Switching time: Rise 5ns / Fall 5ns

Operating temperature range: -55°C to +150°C

Potential applications

Solar energy

Servers

Communications

Consumer products

Adapters

Computer power supplies
