The BSZ520N15NS3G is an N-channel power MOSFET from Infineon, part of the OptiMOS™ 3 series, packaged in a TDSON-8 package (3.3×3.3mm), suitable for high-efficiency power conversion, motor drive, and automotive electronics applications. This device employs advanced MOSFET technology, featuring low on-resistance (RDS(on)), high switching speed, and excellent thermal performance, significantly enhancing system efficiency while reducing PCB space requirements.

Key Features — BSZ520N15NS3G

Low on-resistance: 20mΩ (typical), effectively reducing conduction losses and improving energy efficiency.

High current capability: 21A continuous drain current (ID), suitable for high-power applications.

Fast switching performance:

Rise time 5ns, fall time 3ns, reducing switching losses.

Low gate charge (Qg=12nC @10V), optimising drive efficiency.

High voltage rating: 150V drain-source voltage (VDS), suitable for 48V-80V systems.

Automotive-grade reliability: Compliant with AEC-Q100 standards, operating temperature range -55°C to +150°C.

Compact packaging: TDSON-8 surface mount, saving PCB space and optimising thermal design.

Key parameters

Model: BSZ520N15NS3G

Package: TDSON-8 (3.3×3.3mm)

Drain-source voltage (VDS): 150V

Continuous drain current (ID): 21A

On-resistance (RDS(on)): 20mΩ (typical)

Gate Charge (Qg): 12 nC @10 V

Input Capacitance (Ciss): 890 pF @75 V

Switching Time: Rise 5 ns / Fall 3 ns

Operating Temperature: -55°C to +150°C

Typical Applications — BSZ520N15NS3G

Power Conversion:

AC-DC SMPS synchronous rectification

DC-DC converter (communication/data centre)

Motor Control:

Power tools, home vehicles (48V system)

Industrial servo drives

Automotive Electronics:

48V mild hybrid system (MHEV)

Battery Management System (BMS)

Consumer Electronics:

Class D audio amplifier

UPS uninterruptible power supply

Product Advantages — BSZ520N15NS3G

High Power Density: Compared to competitors, RDS(on) is reduced by 40%, and FOM (Figure of Merit) is optimised by 45%.

Environmental Design: Complies with RoHS halogen-free standards, suitable for green energy applications.

Simplified Design: Single-chip solution replaces traditional dual MOSFET configurations, reducing BOM costs.
