Trade Name:N-Channel Power MOSFET
Brand:INFINEON
Particular Year:21+
Package:PG-TO252-3
Delivery Date:New and Original
Stock: 50000pcs
The IPD70R360P7S is an N-channel power MOSFET developed by Infineon, based on advanced Trench MOSFET technology and incorporating 700V CoolMOS™ P7 super-junction technology. It features ultra-low on-resistance and fast switching characteristics, specifically designed for high-efficiency power conversion applications. This product is widely applicable in switch-mode power supplies, motor drives, DC-DC converters, and other fields, significantly enhancing system efficiency and power density.
Technical Specifications — IPD70R360P7S
Drain-source voltage: 700V
Continuous drain current: 12.5A
On-resistance: 360mΩ @ 10V, 3A
Gate charge: 8.5nC
Input capacitance: 517pF
Operating temperature range: -40°C to +150°C
Package Type: TO-252-3
Product Features — IPD70R360P7S
Low On-Resistance: Extremely low on-resistance reduces power loss and improves system efficiency.
• Fast Switching Speed: Suitable for high-frequency operating environments, helping to reduce the size of magnetic components and achieve higher power density.
• High voltage withstand capability: 700V voltage withstand, ensuring reliability in high-voltage applications.
• Excellent thermal performance: Optimised package design for effective heat dissipation, ensuring device stability during high-power operation.
• Integrated protection functionality: Built-in integrated protection Zener diode enhances the device's resistance to transient overvoltage.
Advantages — IPD70R360P7S
• Cost-competitive technology
• Lower temperature
• Higher electrostatic discharge (ESD) tolerance
• Improved efficiency at higher switching frequencies
• Supports high power density designs and miniaturised structures
Potential applications —IPD70R360P7S
• Recommended for flyback topology structures, such as chargers, adapters, lighting applications, etc.
