For picture reference, please see the specifications
< >

Commodity Model:R7F7016923AFP

Trade Name:32-bit microcontroller - MCU

Brand:Renesas

Particular Year:24+

Package:LQFP-64

Delivery Date:New and Original

Stock: 2000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
Renesas
Model
R7F7016923AFP
Package
LQFP-64
Describe
32-bit microcontroller - MCU 32BIT MCU RH850/F1KM 512K QFP64

Product Description

R7F7016923AFP is a 32-bit automotive-grade microcontroller (MCU) belonging to the RH850/F1KM series, specifically designed for high-reliability automotive electronic applications. It features high performance, low power consumption, and a rich set of peripheral interfaces. The R7F7016923AFP is based on the RH850G3KH 32-bit core, operating at a maximum frequency of 120MHz, with 512KB of flash memory and 32KB of RAM, meeting the demands for high performance and large storage capacity in automotive applications. It is packaged in a 64-pin LFQFP package and operates within a temperature range of -40°C to +125°C, making it suitable for various complex automotive environments.


Features of R7F7016923AFP

Core Architecture: Utilizes the RH850G3KH 32-bit CPU core with a clock speed of 120MHz, supporting a floating-point unit (FPU).

Storage Resources:

512KB Flash (program storage)

64KB RAM (data storage)

64KB data flash (for parameter storage).

Peripheral Interfaces:

Communication Interfaces: 3x CAN/CAN-FD, 2x CSI, 2x UART, 4x LIN, 2x I²C.

Analog Peripherals: 10x 12-bit ADC, 11x 10-bit ADC, supporting high-precision signal acquisition.

PWM & Timers: 24 PWM outputs, supporting 16/32-bit timers.

Power Management:

Operating voltage range: 3.0V to 5.5V, suitable for automotive electronics with wide voltage requirements.

Supports low-power mode (LPS) for optimized energy management.


R7F7016923AFP Parameters

Core: RH850G3KH 32-bit RISC core

Clock speed: Up to 120MHz

Storage capacity: 512KB flash memory, 32KB RAM

Operating voltage: 3.3V / 5V

Package type: 64-LQFP (10x10mm) package, suitable for surface mounting.

Operating temperature range: -40°C to +125°C, compliant with automotive-grade AEC-Q100 standards.


The R7F7016923AFP is widely used in the automotive field, including but not limited to the following applications:

Body Control Module (BCM)

Automotive Gateway

Battery Management System (BMS) for New Energy Vehicles

Advanced Driver Assistance Systems (ADAS)

Industrial Control and Automation
