The HC32F176MATA-LQFP80 is a high-performance 32-bit microcontroller (MCU) based on the ARM Cortex-M0+ core, designed for low-power, high-integration embedded applications such as smart home, industrial control, and consumer electronics.

HC32F176MATA-LQFP80 Key Features

1. Processor and Performance

CPU Core: 48MHz ARM Cortex-M0+, supporting the Thumb-2 instruction set, providing efficient computational capabilities

Low-Power Modes:

3μA @3V Deep Sleep (all clocks disabled, only RAM and register states retained)

10μA @32.768KHz low-speed operation (CPU running, peripherals disabled)

130μA/MHz @24MHz operating mode (CPU running at full speed)

4μs fast wake-up, suitable for battery-powered devices

2. Storage Resources

128KB Flash (supports ISP/ICP/IAP programming)

16KB RAM (with parity check for enhanced stability)

3. Peripherals and Interfaces

GPIO: 72 pins (LQFP80 package)

Timers:

7 16-bit general-purpose timers (support PWM, dead-time protection)

1 20-bit watchdog timer (WDT)

Communication interfaces:

4× UART

2× SPI

2× I²C

Analogue peripherals:

12-bit 1Msps ADC (25 channels)

12-bit 500Ksps DAC (1 channel)

3 voltage comparators (with 6-bit DAC reference)

1 operational amplifier (OPA) (can be used as a DAC buffer)

4. Security and Encryption

AES-128/192/256 hardware encryption engine

TRNG (True Random Number Generator)

CRC16/CRC32 verification module

5. Other Features

LCD driver (supports 4×47/6×45/8×43 segments)

DMA controller (2 channels)

Low voltage detection (LVD) (16-step adjustable)

SWD debug interface

6. Operating Environment

Voltage range: 1.8V to 5.5V

Temperature range: -40°C to +85°C

Package: LQFP80 (12×12mm, 0.5mm pin pitch)

HC32F176MATA-LQFP80 Typical Applications

Smart Home (IoT Gateway, Smart Socket)

Industrial Control (PLC, Motor Driver)

Consumer Electronics (Portable Devices, HMI Panels)

Medical Devices (Low-Power Sensor Terminals)
