For picture reference, please see the specifications
< >

Commodity Model:RTL8211FDI-CG

Trade Name:Ethernet Transceiver

Brand:REALTEK

Particular Year:22+

Package:QFN-40

Delivery Date:New and Original

Stock: 5000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
REALTEK
Model
RTL8211FDI-CG
Package
QFN-40
Describe
Integrated 10/100/1000M Ethernet Precision Transceiver

Product Description

The Realtek RTL8211FDI-CG is a highly integrated Ethernet transceiver that is compatible with 10Base-T, 100Base-TX, and 1000Base-T IEEE 802.3 standards. It provides all the necessary physical layer functions to transmit and receive Ethernet packets over CAT.5 UTP cable. The RTL8211FDI-CG is manufactured to industrial grade standards.


The RTL8211FDI-CG uses state-of-the-art DSP technology and an Analog Front End (AFE) to enable high-speed data transmission and reception over UTP cable. Functions such as Crossover Detection & Auto-Correction, polarity correction, adaptive equalization, cross-talk cancellation, echo cancellation, timing recovery, and error correction are implemented in the RTL8211FD(I)-CG to provide robust transmission and reception capabilities at 10Mbps, 100Mbps, or 1000Mbps.


Data transfer between MAC and PHY is via the Reduced Gigabit Media Independent Interface (RGMII) for 1000Base-T, 10Base-T, and 100Base-TX. The RTL8211FDI-CG supports various RGMII signaling voltages, including 3.3, 2.5, 1.8, and 1.5V.


The RTL8211FDI-CG incorporates a linear Low-Dropout Regulator (LDO) that features high power supply ripple rejection and low output noise. The built-in LDO means a power inductor is not required for the RTL8211FDI-CG; only an output capacitor is required between the 1.0V output and the analog ground for phase compensation, which saves cost and PCB real estate.


Features Of RTL8211FDI-CG

1000Base-T IEEE 802.3ab compatible

100Base-TX IEEE 802.3u compatible

10Base-T IEEE 802.3 compatible

Supports RGMII

Supports IEEE 802.3az-2010 (Energy Efficient Ethernet)

Built-in Wake-on-LAN (WOL)

Supports Interrupt function

Supports Parallel Detection

Crossover Detection & Auto-Correction

Automatic polarity correction

Supports PHYRSTB core power Turn-Off

Baseline Wander Correction

Supports 120m for CAT.5 cable in 1000Base-T

Selectable 3.3/2.5/1.8/1.5V signaling for RGMII

Supports 25MHz external crystal or OSC

Provides 125MHz clock source for MAC

Provides 3 network status LEDs

Supports Link Down power saving

Green Ethernet (1000/100Mbps mode only)

Built-in Switching LDO

40-pin QFN Green package

55 nm process with ultra-low power consumption

Industrial grade manufacturing process (RTL8211FDI-CG)


Applications Of RTL8211FDI-CG

DTV (Digital TV)

MAU (Media Access Unit)

CNR (Communication and Network Riser)

Game Console

Printer and Office Machine

DVD Player and Recorder

Ethernet Hub

Ethernet Switch


In addition, the RTL8211FDI-CG can be used in any embedded system with an Ethernet MAC that needs a UTP physical connection.

Associated Products

Model

Brand

Package

Quantity

Describe

BCM84864A0KFSBG

BROADCOM

BGA

2600

High-performance Ethernet physical layer transceiver (PHY)

BCM54219SB0IMLG

BROADCOM

BGA

2000

10/100/1000BASE-T Gigabit Ethernet Transceiver

BCM54616SC0IFBG

BROADCOM

BGA

5000

10/100/1000base-t Gigabit Copper Transceiver

TLK2501IRCPR

TI

HVQFP-64

3000

1.5Gbps to 2.5Gbps transceivers

BCM84884B0KFSBG

BROADCOM

BGA

3000

Single-chip integrated quad-port Ethernet CMOS transceiver

LAN8720AI-CP

Microchip

QFN-24

10000

Small Footprint RMII 10/100 Ethernet Transceiver with HP Auto-MDIX Support

RTL8201GR-VB-CG

REALTEK

QFN-24

3000

Single Port 10/100M Ethernet Network Transceiver, QFN-24

RTL8221B-VM-CG

REALTEK

QFN-48

3000

Integrated 10/100/1000M/2.5G Ethernet Transceiver, QFN-48

BCM85822

BROADCOM

BGA

2000

5-nm CMOS 800G (8:4) PAM-4 Transceiver PHY with Integrated Laser Driver

88E1548PA0-BAM2C000

Marvell

TFBGA-196

10000

Quad-Port 10/100/1000 Mbps Ethernet Transceiver with QSGMII or SGMII Interface
