For picture reference, please see the specifications
< >

Commodity Model:AR8033-AL1A

Trade Name:Ethernet Transceiver

Brand:QUALCOMM

Particular Year:21+

Package:QFN-48

Delivery Date:New and Original

Stock: 13000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
QUALCOMM
Model
AR8033-AL1A
Package
QFN-48
Describe
Single-port 10/100/1000 Mbps tri-speed Ethernet PHY transceiver

Product Description

The AR8033-AL1A is a single-port 10/100/1000 Mbps tri-speed Ethernet PHY transceiver in a 48-pin QFN-EP (6×6mm) package, supporting RGMII and SGMII interfaces, and is suitable for applications such as home gateways, enterprise switches, industrial automation, optical modules, IP cameras, and NAS storage. The chip incorporates low-power design and green energy-saving technology, compliant with the IEEE 802.3az Energy Efficient Ethernet (EEE) standard, significantly reducing system power consumption.


AR8033-AL1A Core Features

1. High-Performance Network Transmission

Supports 10/100/1000 Mbps auto-negotiation rates, compatible with the IEEE 802.3 standard.

Supports RGMII (Reduced Gigabit Media Independent Interface) and SGMII (Serial Gigabit Media Independent Interface) for easy connection with various MAC chips.

Integrated 1.25 Gbps SerDes (Serialiser/Deserialiser) for direct connection to 1000BASE-X/100BASE-FX fibre modules.

2. Low Power Consumption and Energy-Saving Technology

Supports IEEE 802.3az Energy Efficient Ethernet (EEE) to reduce power consumption in idle states.

SmartEEE™ technology is compatible with traditional MAC devices that do not support EEE.

Ultra-low power consumption cable removal mode further optimises energy efficiency.

3. Enhanced Features

Cable Diagnostic Test (CDT) detects cable length, status, and faults.

Supports Wake-on-LAN (WoL) for remote system wake-up.

Automatic MDI/MDIX crossover and polarity correction simplifies cabling design.

4. Industrial-Grade Reliability

Operating temperature range: 0°C to 70°C (commercial grade).

Compliant with RoHS standards, lead-free eco-friendly design.

±6kV cable discharge event (CDE) protection, enhancing interference resistance.


AR8033-AL1A Typical Applications

Home networks: routers, gateways, IPTV set-top boxes

Enterprise networks: switches, servers, NAS storage

Industrial automation: PLCs, industrial control devices

Optical communications: fibre optic transceiver modules, media converters

Associated Products

Model

Brand

Package

Quantity

Describe

LAN8700C-AEZG

Microchip

QFN-36

9000

10/100 Base-T/TX Physical Layer Transceiver

KSZ8081RNAIA

Microchip

VQFN-24

298000

10BASE-T/100BASE-TX PHY with RMII Support

RTL8211FDI-CG

REALTEK

QFN-40

5000

Integrated 10/100/1000M Ethernet Precision Transceiver

BCM84864A0KFSBG

BROADCOM

BGA

2600

High-performance Ethernet physical layer transceiver (PHY)

BCM54219SB0IMLG

BROADCOM

BGA

2000

10/100/1000BASE-T Gigabit Ethernet Transceiver

BCM54616SC0IFBG

BROADCOM

BGA

5000

10/100/1000base-t Gigabit Copper Transceiver

TLK2501IRCPR

TI

HVQFP-64

3000

1.5Gbps to 2.5Gbps transceivers

BCM84884B0KFSBG

BROADCOM

BGA

3000

Single-chip integrated quad-port Ethernet CMOS transceiver

LAN8720AI-CP

Microchip

QFN-24

10000

Small Footprint RMII 10/100 Ethernet Transceiver with HP Auto-MDIX Support

RTL8201GR-VB-CG

REALTEK

QFN-24

3000

Single Port 10/100M Ethernet Network Transceiver, QFN-24
