The KSZ8081RNACA is a single-supply 10Base-T/100Base-TX Ethernet physical layer (PHY) transceiver for data transmission and reception over standard CAT-5 unshielded twisted pair (UTP) cable. It is a highly integrated PHY solution featuring on-chip termination resistors and an integrated low-noise regulator for 1.2V core power supply, providing 1.8/2.5/3.3V digital I/O interface support.

KSZ8081RNACA Features

Interface Support: Provides a simplified media-independent interface (RMII) that can be directly connected to the MAC of Ethernet processors and switches (RMII compliant).

Auto-negotiation: Automatically selects the highest link speed (10/100 Mbps) and duplex mode (half/full).

Low-power mode: Supports power-down and power-saving modes.

Diagnostic functions: Features LinkMD TDR cable diagnostic functionality to identify faulty copper cables.

High integration: On-chip termination resistors and low-noise regulators reduce the need for external components, lowering costs and simplifying PCB layout.

KSZ8081RNACA Specifications

Operating voltage: 1.8V; 2.5V; 3.3V

Data transfer rate: 10/100 Mbps

Package type: QFN-24

Number of pins: 24

MAC interface type: MII/RMII

Operating temperature range: 0°C to +70°C

ESD protection: Supported

KSZ8081RNACA Applications

Home and consumer electronics: such as home gateways, IP cameras, printers, etc.

Industrial control: suitable for controllers, PLCs, and other networked hardware in industrial automation applications.

Embedded devices: such as robots, medical devices, etc.

IoT devices: used for data transmission between IoT nodes, such as smart homes, smart cities, etc.

Network devices: used in small network devices, such as routers, switches, etc.
