The RTL8367S-CG is a high-performance 5+2-port 10/100/1000M Ethernet switch chip developed by Realtek Semiconductor, packaged in an LQFP-128 package. It integrates a low-power 5-port Giga-PHY, supporting 1000Base-T, 100Base-TX, and 10Base-T, capable of meeting the high-speed connectivity requirements of various network devices.

Model: RTL8367S-CG

Type: Ethernet Switch

Package: LQFP-128 (14×14 mm)

Operating Temperature: -40°C to +85°C (industrial grade)

Compliant Standards: IEEE 802.3 (Ethernet), IEEE 802.1Q (VLAN), IEEE 802.1x (Network Access Control)

RTL8367S-CG Technical Specifications:

Port Configuration: 5 10/100/1000Base-T Ethernet ports and 2 additional interfaces (configurable as SGMII, HSGMII, RGMII, or MII).

Data Rate: Supports full-duplex and half-duplex modes, with a data rate of up to 1000 Mbps.

Packet Processing: Supports line-rate forwarding of 9216-byte jumbo packets, with flow control and backpressure functionality.

VLAN Support: Supports IEEE 802.1Q VLANs, with up to 4K VLANs and 32 enhanced VLANs.

MAC Address Table: Features a 2K-entry MAC address table, supporting 4-way XOR hash algorithms.

Filtering database: Supports up to 2K entries in the L2/L3 filtering database.

Rate limiting: Supports 32 shared counters, with rate limiting precision up to 8 kbps.

Operating voltage: 3.3V

Typical applications

Enterprise network switches: Small and medium-sized office networks, smart gateways.

Industrial Ethernet: PLC communication, industrial automation control.

Smart home: Multi-port gigabit routers, NAS storage devices.

In-vehicle networks: In-vehicle infotainment systems (must comply with AEC-Q100 standards).
