The RTL8197FS-VE4-CG is a highly integrated 2T2R 802.11b/g/n WiSoC (wireless system-on-chip) launched by Realtek, primarily designed for applications such as smart routers, IoT gateways, and network storage devices. The chip integrates a 1GHz MIPS24Kc processor, Wi-Fi MAC/BB/RF, Ethernet switching, USB controller, and other functions, featuring high performance and low power consumption.

RTL8197FS-VE4-CG Key Features

Processor (CPU)

MIPS24Kc architecture, 1GHz clock speed

64KB instruction cache (I-Cache) + 32KB data cache (D-Cache)

Wireless Network (Wi-Fi)

2.4GHz 2T2R 802.11b/g/n, with a maximum PHY rate of 300Mbps

Supports MIMO (Multiple Input Multiple Output) technology to enhance signal stability

Network Interface

5-port Fast Ethernet switch (with RGMII interface)

PCI Express 1.1 interface (supports 5 Gbps transmission)

USB 2.0 controller (supports 480 Mbps high-speed mode)

Storage Support

DDR1/DDR2 memory interface (16-bit)

SPI NOR/NAND Flash and parallel NAND Flash controller

Peripheral Interfaces

SDXC/eMMC (supports high-speed storage cards)

SPI, UART, I²C, I²S, PCM (for audio and communication)

4-channel PWM, 4-channel timers (for control applications)

Security and Power Optimisation

Hardware encryption engine (supports secure communication)

Low-power design, suitable for IoT gateways, smart home devices

RTL8197FS-VE4-CG Typical Applications

Smart routers (e.g., 360 Security Router V4, Huawei WS5200)

IoT gateways

VPN/VoIP gateways

LTE routers & network storage devices
