The SC33PF8100JCES is a 12-channel power management integrated circuit (PMIC) designed for high performance applications. The chip integrates a variety of power management and protection functions for electronic systems requiring high efficiency and reliability, especially in automotive electronics and industrial control.

Product Features (SC33PF8100JCES)

High Efficiency Buck Converters: The SC33PF8100JCES includes up to seven high-efficiency buck converters that provide up to 90% conversion efficiency.

Linear Regulators: Featuring four linear regulators, each with load switching options for flexible configuration of output voltage and current.

RTC Power Supply and Coin Battery Charger: Provides an RTC (Real Time Clock) power supply and coin battery charger function to ensure that the system maintains accurate time in the event of a power failure.

Watchdog Timer and Monitoring Function: Built-in watchdog timer and monitoring circuitry monitors system status to ensure stable system operation in accordance with Automotive Safety Integrity Level (ASIL) B requirements.

One-time programmable (OTP) device configuration: OTP configuration is supported, allowing users to customise settings according to specific application requirements.

Multiple protection functions: including over-current protection, over-voltage protection, short-circuit protection, etc., which improves the reliability and safety of the system.

Technical Specifications (SC33PF8100JCES)

Package form: HVQFN package with good thermal performance and mechanical stability

Operating temperature range: Wide temperature range from -40°C to 105°C, suitable for various harsh operating environments.

Number of step-down DC/DC converters: 7

Number of low dropout regulators: 4

Number of rectifier outputs: 12

Supply voltage: Supports 5.5V supply voltage

Application Scenarios (SC33PF8100JCES)

Automotive electronics: Suitable for various electronic control units (ECUs) in automobiles, such as instrument clusters, infotainment systems, advanced driver assistance systems (ADAS), etc., providing stable and reliable power management for automotive electronic systems.

Industrial control: In industrial automation equipment and robot control systems, SC33PF8100JCES can provide efficient power management for processors, sensors and other key components to improve overall system performance and reliability.

Embedded system: In embedded applications that require high-performance power management, such as network equipment, communication base stations, etc., the chip can ensure stable system operation and efficient energy conversion.
