BSZ42DN25NS3G 250V OptiMOS™ 3 N-Channel Power MOSFET Transistors is performance leading benchmark technologies, perfectly suited for synchronous rectification in 48V systems, DC-DC converters, uninterruptable power supplies (UPS) and inverters for DC motor drives.

Specification Of BSZ42DN25NS3G

Transistor Polarity:N-Channel

Number of Channels:1 Channel

Vds - Drain-Source Breakdown Voltage:250 V

Id - Continuous Drain Current:5 A

Rds On - Drain-Source Resistance:371 mOhms

Vgs - Gate-Source Voltage:- 20 V, + 20 V

Vgs th - Gate-Source Threshold Voltage:2 V

Qg - Gate Charge:5.5 nC

Minimum Operating Temperature:- 55 C

Maximum Operating Temperature:+ 150 C

Pd - Power Dissipation:33.8 W

Channel Mode:Enhancement

Configuration:Single

Fall Time:5 ns

Forward Transconductance - Min:3 S

Height:1.1 mm

Length:3.3 mm

Product Type:MOSFETs

Rise Time:2 ns

Typical Turn-Off Delay Time:8 ns

Typical Turn-On Delay Time:3 ns

Width:3.3 mm

Unit Weight:38.760 mg

Features Of BSZ42DN25NS3G

Optimized for dc-dc conversion

N-channel, normal level

Excellent gate charge x R DS(on) product (FOM)

Low on-resistance R DS(on)

150 °C operating temperature

Pb-free lead plating; RoHS compliant

Qualified according to JEDEC1) for target application

Halogen-free according to IEC61249-2-21

Benefits Of BSZ42DN25NS3G

Highest efficiency

Highest Power density

Lowest board space consumption

Minimal device paralleling required

System cost improvement

Enviromentally friendly

Easy-to-design-in products

Applications Of BSZ42DN25NS3G

Synchronous rectification for AC-DC SMPS

Motor control for 48V–110V systems

Isolated DC-DC converters

Lighting for 110V AC networks

HID lamps

Class D audio amplifiers

Uninterruptable power supplies (UPS)

48 V to 12 V DC-DC converter
