The IRF1310NPBF is a 100V single N-channel power MOSFET in a TO-220 package.

Features - IRF1310NPBF

Planar cell structure for wide SOA

Optimised for widest availability from distribution partners

JEDEC-compliant products

Silicon optimised for applications with switching frequencies below 100kHz

Industry standard surface mount power supply package

High current rating

Benefits - IRF1310NPBF

More rugged

Wide range of distribution partner offerings

Meets industry standards

High performance in low frequency applications

Direct replacement for existing equipment

High current capability

Specification - IRF1310NPBF

FET Type: N-Channel

Technology: MOSFET (Metal Oxide)

Drain-Source Voltage (Vdss): 100 V

Current at 25°C - Continuous Drain (Id) : 42A (Tc)

Drive voltage (max. Rds On, min. Rds On): 10V

On-resistance (max) at different Id, Vgs: 36 mOhm @ 22A, 10V

Vgs(th) at different Id (max): 4V @ 250µA

Gate Charge (Qg) (Max) at Vgs: 110 nC @ 10 V

Vgs (max): ±20V

Input capacitance (Ciss) at different Vds (max): 1900 pF @ 25 V

Power Dissipation (Max): 160W (Tc)

Operating Temperature: -55°C ~ 175°C (TJ)

Mounting Type: Through Hole

Supplier Device Package: TO-220AB

Package/Housing: TO-220-3
