The TLE4988C-XTS-M28 is a camshaft sensor based on Hall, featuring advanced camshaft detection performance and improved application adaptability. This sensor features proven performance and employs ferrite reverse-biased magnets, making it suitable for all relevant parameters such as phase jitter, phase accuracy, or velocity effects within critical temperatures, air gaps, and rpm ranges.

Performance parameters

The TLE4988C-XTS-M28 has the following parameters:

Technology: Hall Effect

Sensing range: -31.1mT to 134.6mT

Voltage - Power supply: 4V to 24V

Current - Power Supply (maximum value) : 8.8mA

Current - Output (maximum value) : 15mA

Output type: Open circuit drain

Features: Programmable, temperature compensation

Operating temperature: -40°C to 195°C (TJ)

Installation type: Through hole

Device packaging: PG-SSO-3-52

Through automatic on-board calibration, the most accurate detection is ensured in the actual application environment, and the tolerances of ferromagnetic wheels and magnetic encoders as well as the installation tolerances of sensors are solved. The TLE4988C-XTS-M28 can compensate for the thermal stress or mechanical stress applied during the module manufacturing process. Embedded EEPROM can also adopt a unique chip ID to achieve logistics traceability (upon request). High-speed digital I/F supports rapid register reading for diagnostic or testing purposes.
