The A19420LUBBTN is an optimized Hall-effect integrated circuit (IC) that measures the speed of rotating targets. This sensor IC can be used to directly measure ring magnets or be back-biased with a magnet to measure ferrous targets. The package features an integrated capacitor for electromagnetic compatibility (EMC).

The A19420LUBBTN SolidSpeed Digital Architecture offers intelligent algorithms capable of stable operation during sudden and dynamic air gap movements. The sophisticated digital controller provides highly accurate speed detection ideal for transmission applications. In addition, the A19420 differential sensing offers inherent rejection of interfering common-mode magnetic fields.

The A19420LUBBTN was developed in accordance with ISO 26262:2011 as a hardware safety element out of context with ASIL B capability for use in automotive safety-related systems when integrated and used in the manner prescribed in the applicable safety manual and datasheet.

The A19420LUBBTN is provided in a 2-pin SIP package (suffix UB) that is lead (Pb) free, with tin leadframe plating. The UB package includes an IC and capacitor integrated into a single overmolded package, with an additional molded lead-stabilizing bar for robust shipping and ease of assembly.

Features and Benefits

• Differential Hall-effect sensor measures ring magnets and ferrous targets with inherent stray field immunity

• SolidSpeed Digital Architecture supports advanced algorithms, maintaining pitch and duty cycle accuracy during dynamic air gap disturbances

• Integrated solution includes a capacitor in a single overmolded package

• ISO 26262:2011 ASIL B with integrated diagnostics and certified safety design process

• Two-wire current source output protocol supporting speed and ASIL error reporting

• EEPROM enables traceability throughout product life cycle
