The XENSIV™ TLE4959-5U magnetic sensor features a four-pin package that complies with RoHS standards and is suitable for the automotive field. This device has the following functions and technical specifications:

A functional overview of TLE4959-5U

Differential sensor based on Hall

High magnetic sensitivity

Large working air gap

Dynamic self-calibration principle

Adaptive lag

Rotation direction detection

High vibration suppression capability

Three-wire PWM voltage interface

The application of magnetic encoders and ferromagnetic wheels

High immunity to ESD, EMC and mechanical stress, as well as improved voltage drop capability

The operating temperature range of automobiles

Passed the EC-100 certification

The main specifications of TLE4959-5U include:

Type: Speed & Current Sensors

Working power supply current: 13.4 mA

Maximum output current: 15 mA

Minimum/maximum working point: -120 mT to 120 mT

Working power supply voltage: 4 V to 16 V

Minimum operating temperature: -40 ° C

Maximum operating temperature: + 175 ° C

Installation style: Through Hole

Encapsulation: PG-SSO-4

Power supply voltage - Maximum: 16 V

Power supply voltage - minimum: 4 V
