The BSC028N06LS3G is an N-channel enhancement power MOSFET in a TDSON-8 package.The BSC028N06LS3G OptiMOS™ 60 V is ideal for synchronous rectification of switched-mode power supplies (SMPS), such as servers, desktops, and tablet chargers.

BSC028N06LS3G Key Features:

Low on-resistance: Maximum on-resistance (RDS(on)) of 2.8 milliohms (VGS=10V, ID=50A) helps to reduce on-resistance losses and improve power supply efficiency.

High Current Carrying Capability: Continuous drain current (ID) of up to 100 amps meets the needs of various high-current applications.

Fast Switching Speed: Fast switching speed reduces switching losses and improves circuit efficiency.

Excellent Thermal Stability: The TDSON-8 package provides good thermal characteristics and effective heat dissipation to ensure stable operation in high power applications.

Wide operating temperature range: Operating temperature range of -55°C to +150°C ensures reliability and stability in harsh environments.

BSC028N06LS3G Specifications:

Drain-source voltage (VDS): 60V

Gate Source Voltage (VGS): -20V to +20V range

Power dissipation (Ptot): 139W maximum (TC=25°C)

Input capacitance (Ciss): 10000pF (VDS=30V)

Reverse transfer capacitance (Crss) : 2.3nF (VDS=30V)

Threshold voltage (VGS(th)) : 2.0V to 3.0V

BSC028N06LS3G Potential Applications:

Synchronous rectification

Solar microinverters

Isolated DC-DC converters

Motor control for 12-48 V systems

Dimmer switches
