Trade Name:Battery Management
Brand:TI
Particular Year:19+
Package:HTQFP-64
Delivery Date:New and Original
Stock: 6000pcs
The BQ76PL536ATPAPRQ1 device is a stackable battery monitor and protector for three to six series-connected lithium-ion batteries.The BQ76PL536ATPAPRQ1 integrates an analogue front-end (AFE) and a precision analogue-to-digital converter (ADC) to accurately measure battery voltage. A separate ADC is used to measure temperature.
In addition to measuring temperature, the device provides overvoltage and undervoltage monitoring protection for each channel. User-programmable protection thresholds and delay times are stored via non-volatile memory. Once one of these thresholds is exceeded, a fault signal is output.
Support for a 192-cell battery pack can be achieved by stacking the BQ76PL536ATPAPRQ1 devices.
BQ76PL536ATPAPRQ1 Features
Automotive Compliant Application Approvals
Has the following results in accordance with the AEC-Q100 standard:
Device Temperature Level 2: -40°C to +105°C ambient operating temperature range
Device Human Body Model (HBM) Classification Level 2
Device Charging Device Model (CDM) Classification Level C4B
3-cell to 6-cell battery support, all compounds
Hot Swap
High-speed serial peripheral interface (SPI) for data communication
Interface supports vertical stacking
No isolation components required between devices
High-precision analogue-to-digital converter (ADC)
±1mV typical accuracy
14-bit resolution, 6µs conversion time
Nine ADC inputs
Dedicated pins to support simultaneous measurements
Configuration data stored in one-time programmable (OTP) register with error check/correction (ECC) function
Built-in comparator (secondary protector) support:
Overvoltage and undervoltage protection
Thermal protection
Programmable thresholds and delay times
Dedicated fault signalling
Cell equalisation control output supporting safety time-out function
Equalisation current set via external component
Supply voltage range: 7.2V to 27V continuous and 36V peak
Low power consumption:
12µA typical sleep current, 45µA typical idle current
Integrated 5V, 3mA high-precision LDOs
Applications of BQ76PL536ATPAPRQ1
Electric and hybrid vehicles
Uninterruptible power systems (UPS)
Electric bicycles and electric motorbikes
Large battery systems
Model
Brand
Package
Quantity
Describe
INFINEON
TQFP-48
2500
Battery management multi-functional controller IC lithium-ion PG-TQFP-48
ADI
SSOP-48
3000
4th generation 12-channel multi-unit battery monitor with integrated Daisy link port
ADI
SSOP-48
4000
4th generation 12-channel multi-unit battery monitor with integrated Daisy link port
TI
HTQFP-64
5000
ASIL-D compliant automotive grade 16 cell series precision battery monitor, balancer and integrated protector
