The MSP430F5329IPNR is an ultra-low-power 16-bit RISC architecture microcontroller belonging to the F5x sub-family of the MSP430 family. It integrates high-performance peripherals and a rich set of function blocks for application scenarios that require low power consumption, high integration, and efficient processing power.

Product features - MSP430F5329IPNR

Low-power design:

Power consumption is 290µA/MHz (typical) in activation mode (AM) at 8MHz, 3V and Flash programme execution, and 150µA/MHz (typical) at 8MHz, 3V and RAM programme execution.

Standby mode (LPM3) with real-time clock (RTC) with crystal, watchdog, power monitor available, full RAM hold, and fast wake-up consumes 1.9µA at 2.2V and 2.1µA at 3V (typical).

Low-power oscillator (VLO), general-purpose counter, watchdog, power monitor available, full RAM hold, fast wake-up, 1.4µA at 3V (typical).

Shutdown mode (LPM4), full RAM hold, power monitor available, fast wake-up, 1.1µA at 3V typical.

Shutdown mode (LPM4.5) with power consumption of 0.18µA at 3V (typical).

Wake-up from standby mode in 3.5µs (typical).

High-performance 16-bit RISC CPU: Supports efficient instruction execution with 16-bit registers and constant generators for maximum code efficiency.

Rich peripheral integration:

Built-in flexible power management system, including built-in programmable low dropout regulators (LDOs), supply voltage monitoring, surveillance and temporary power-limit functions.

Unified clock system, including phase-locked loop (FLL) control loop for frequency stabilisation, low-power low-frequency internal clock source (VLO), low-frequency trimmed internal reference source (REFO), 32kHz watch crystal (XT1), and high-frequency crystal up to 32MHz (XT2).

16-bit timer TA0, Timer_A, with 5 capture/compare registers; 16-bit timer TA1, Timer_A, with 3 capture/compare registers; 16-bit timer TA2, Timer_A, with 3 capture/compare registers; 16-bit timer TB0, Timer_B, with 7 capture/compare shadow registers.

Two Universal Serial Communication Interfaces (USCIs), USCI_A0 and USCI_A1, both support Enhanced Universal Asynchronous Transceiver (UART) with automatic baud rate detection, IrDA encoding and decoding, and Synchronous Serial Peripheral Interface (SPI); USCI_B0 and USCI_B1, each support I2C, Synchronous SPI.

Integrated 3.3V power system.

12-bit analogue-to-digital converter (ADC) with internal reference, sample hold, and auto-scan.

Comparator.

Hardware multiplier supports 32-bit operations.

Serial on-board programming, no external programming voltage required.

3-channel internal DMA.

Basic timer with RTC characteristics.

High memory capacity: 128KB Flash, 10KB SRAM.

Flexible installation: Supports on-chip debug function to simplify the development and debugging process, wide operating voltage range (1.8V~3.6V) for better adaptability, and small package options to save board space.

Technical parameters-MSP430F5329IPNR

CPU core: MSP430

CPU Maximum main frequency: 25MHz

Programme memory capacity: 128KB (128K x 8)

Programme memory type: FLASH

Data memory type: SRAM

Data storage capacity: 10KB (10K x 8)

Number of I/O : 63

ADC (number of bits): 12bit, 16 channels

Operating Voltage: 1.8V~3.6V

Operating temperature range: -40°C~+85°C (TA)

Package: LQFP-80 (12x12)

Applications - MSP430F5329IPNR

- Analogue and digital sensor systems

- Data Logger

- General Purpose Applications
