Commodity Model:S9S12VR48AF0VLFR

Trade Name:16-bit Microcontroller - MCU

Brand:NXP

Particular Year:22+

Package:LQFP-48

Delivery Date:New and Original

Stock: 4000pcs

Quantity:
Online Inquiry

Contacts:

E-Mail:

Contact Number:

Corporate Name:

Product Parameters

Manufacturer
NXP
Model
S9S12VR48AF0VLFR
Package
LQFP-48
Describe
MagniV 16-bit MCU, S12 core, 48KB Flash, 25MHz, -40/+105degC, Automotive Qualified, QFP 48

Product Description

The S9S12VR48AF0VLFR is a 16-bit automotive-grade microcontroller (MCU) developed by NXP, part of the S12 MagniV series, specifically optimised for low-cost, high-performance, low-pin-count automotive electronic applications. The chip integrates a LIN physical interface, a 5V regulator system, relay drivers, and high-voltage input detection, making it suitable for applications such as window lift modules, seat control, and smart actuators in body electronics systems.


S9S12VR48AF0VLFR Specifications

• Core: 16-bit S12, 25 MHz

• Memory: 48 KB Flash / 2 KB SRAM / 512 B EEPROM

• I/O: 28-channel general-purpose GPIO

• Communication: LINbus, SPI, SCI, IrDA

• Data conversion: 6×10-bit ADC

• Clock: Internal oscillator

• Package: 48-LQFP (7 mm × 7 mm)

• Grade: AEC-Q100


Features

S12 (up to 25 MHz) 16-bit CPU

16 to 64 kB Flash with ECC

Voltage regulator powered directly from the vehicle battery

LIN physical layer

2 low-side drivers (typically used for relays)

1 low-side driver (only in S12VRP)

1–2 high-side drivers

4–6 high-voltage inputs for switch monitoring

On-chip RC oscillator with ±1.3% accuracy
